Thiết bị FortiAnalyzer-FAZ-200F
|
FORTIANALYZER APPLIANCES |
FORTIANALYZER 200F |
|
Capacity and Performance |
|
|
GB/Day of Logs |
100 |
|
Analytic Sustained Rate (logs/sec) |
3000 |
|
Collector Sustained Rate (logs/sec) |
4500 |
|
Devices/VDOMs (Maximum) |
150 |
|
Max Number of Days Analytics |
40 |
|
Options |
|
|
FortiGuard Indicator of Compromise (IOC) |
#FC-10-L200F-149-02-12 (1-Year) |
|
Hardware Specifications |
|
|
Form Factor (supports EIA/non-EIA standards) |
1 RU Rackmount |
|
Total Interfaces |
2 x RJ45 GE |
|
Storage Capacity |
4 TB (1 x 4 TB) |
|
Usable Storage (After RAID) |
4 TB |
|
RAID Levels Supported |
N/A |
|
RAID Type |
N/A |
|
Default RAID Level |
N/A |
|
Dimensions |
|
|
Height x Width x Length (inches) |
1.75 x 17.0 x 15.0 |
|
Height x Width x Length (cm) |
4.4 x 43.2 x 38.1 |
|
Weight |
17.1 lbs (7.8 kg) |
|
Environment |
|
|
AC Power Supply |
100–240V AC, 50–60 Hz |
|
Power Consumption (Average / Maximum) |
49W / 114 W |
|
Heat Dissipation |
390 BTU/h |
|
Operating Temperature |
32–104° F (0–40° C) |
|
Storage Temperature |
95–158° F (-35–70° C) |
|
Humidity |
20 to 90% non-condensing |
|
Compliance |
|
|
Safety Certifications |
FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB |
