HPE MSA 2050 (Q1J00A)
|
Model |
HPE MSA 2050 (Q1J00A) |
|
Access Type |
Block |
|
Form Factor |
2U, SFF or LFF |
|
Number of controllers per array |
2 |
|
Minimum / Maximum host posts |
1/8 |
|
FC host connectivity |
8/16Gb |
|
iSCSI host connectivity |
1Gb or 10Gb |
|
Max Read cache per array |
8TB |
|
Data (read/write) cache + system memory per array |
16GB |
|
Pool Capacity (with large pool support) |
562 TB (512 TiB) |
|
RAID Levels supported: virtual mode |
RAID 1, 5, 6, 10 |
|
Expansion Drive Enclosures |
0-7 enclosures |
|
LFF/SFF array/enclosure mixing |
Supported |
|
Maximum number of drives per array enclosure |
24 SFF/12 LFF |
|
Maximum number of drives per drive enclosure |
24 SFF/12 LFF |
|
Drive enclosure inter face type |
6 Gb SAS |
|
Maximum total HDDs per array |
192 SFF / 96 LFF |
|
Maximum total SSDs per array |
192 SFF / 96 LFF |
|
Max raw capacity per array enclosure |
76.8 TB SFF / 120TB LFF |
|
Max raw capacity per drive enclosure |
76.8 TB SFF / 120TB LFF |
|
Max raw capacity per array |
614.4TB SFF / 960TB LFF |
|
SFF SSDs (Mixed Use) |
400GB, 800GB, 1.6TB, 3.2TB |
|
LFF SSDs (Mixed Use) |
400GB, 800GB |
|
SFF HDDs |
15K: 300GB, 600GB, 900GB 10K: 300GB, 600GB, 900GB, 1.2TB, 1.8TB 7.2K: 1.0TB, 2.0TB |
|
LFF HDDs |
7.2K: 2TB, 4TB, 6TB, 8TB, 10TB |
