Model

6900 Security Gateway

Performance

Enterprise Test Conditions

Threat Prevention1 (Gbps) 7.4
NGFW2 (Gbps) 17
IPS (Gbps) 19
Firewall (Gbps) 37

RFC 3511, 2544, 2647, 1242 PERFORMANCE (LAB)

Firewall 1518B UDP (Gbps) 63
VPN AES-128 (Gbps) 9.81
Connections/sec 230,000
Concurrent connections 4/8/16M

Additional Features

Highlights

• 1x CPUs, 8 physical cores, 16 virtual cores
• 1x 480GB SSD storage (2x in Plus)
• 1 AC or DC power supply (2x in Plus)
• 16, 32 and 64 GB memory options
• Lights-Out-Management (included in Plus)
• Virtual Systems (Base/Plus/max mem): 10/20/20

Network Expansion Slot Options (2 of 2 slots open)

• 8x 10/100/1000Base-T RJ45 port card, up to 26 ports
• 4x 1000Base-F SFP port card, up to 8 ports
• 4x 10GBase-F SFP+ port card, up to 8 ports
• 2x 40GBase-F QSFP+ port card, up to 4 ports

Content Security

First Time Prevention Capabilities

• CPU-level, OS-level and static file analysis
• File disarm and reconstruction via Threat Extraction
• Average emulation time for unknown files that require full sandbox evaluation is under 100 seconds
• Maximal file size for Emulation is 100 MB
• Emulation OS Support: Windows XP, 7, 8.1, 10

Applications

• Use 8,000+ pre-defined or customize your own applications
• Accept, prevent, schedule, and apply traffic-shaping

Data Loss Prevention

• Classify 700+ pre-defined data types
• End user and data owner incident handling

Dynamic User-based Policy

• Integrates with Microsoft AD, LDAP, RADIUS, Cisco pxGrid, Terminal Servers and with 3rd parties via a Web API
• Enforce consistent policy for local and remote users on Windows, macOS, Linux, Android and Apple iOS platforms

Network

Network Connectivity

• Total physical and virtual (VLAN) interfaces per appliance: 1024/4096 (single gateway/with virtual systems)
• 802.3ad passive and active link aggregation
• Layer 2 (transparent) and Layer 3 (routing) mode

High Availability

• Active/Active L2, Active/Passive L2 and L3
• Session failover for routing change, device and link failure
• ClusterXL or VRRP

IPv6

• NAT66, NAT64, NAT46
• CoreXL, SecureXL, HA with VRRPv3

Unicast and Multicast Routing (see SK98226)

• OSPFv2 and v3, BGP, RIP
• Static routes, Multicast routes
• Policy-based routing
• PIM-SM, PIM-SSM, PIM-DM, IGMP v2, and v3

Physical

Power Requirements

• Single Power Supply rating: 300W
• AC power input: 100 to 240V (47-63Hz)
• Power consumption avg/max: 139W/275W
• Maximum thermal output: 938 BTU/hr

Dimensions

• Enclosure: 1RU
• Dimensions (WxDxH): 17.2 x 20 x 1.73 in. (438 x 508 x 44mm)
• Weight (Base/Plus): 17.6/19.8 lbs. (8.45/9 kg)

Environmental Conditions

• Operating: 0° to 40°C, humidity 95%
• Storage: –20° to 70°C, humidity 95%
