Thiết bị FortiGate FG-60F-BDL -950-12

Mã sản phẩm

FG-60F

Hardware Specifications

GE RJ45 WAN / DMZ Ports

2 / 1

GE RJ45 Internal Ports

5

GE RJ45 FortiLink Ports

2

GE RJ45 PoE/+ Ports

-

Wireless Interface

-

Console Port

1

USB Port

1

Internal Storage

-

System Performance — Enterprise Traffic Mix

IPS Throughput

1.4 Gbps

NGFW Throughput

1 Gbps

Threat Protection Throughput

700 Mbps

System Performance

Firewall Throughput (1518 / 512 / 64 byte UDP packets)

10/10/6 Gbps

Firewall Latency (64 byte, UDP)

3.3 μs

Firewall Throughput (Packet per Second)

9 Mpps

Concurrent Sessions (TCP)

700,000

New Sessions/Sec (TCP)

35,000

Firewall Policies

5,000

IPsec VPN Throughput (512 byte)

6.5 Gbps

Gateway-to-Gateway IPsec VPN Tunnels

200

Client-to-Gateway IPsec VPN Tunnels

500

SSL-VPN Throughput

900 Mbps

Concurrent SSL-VPN Users

200

SSL Inspection Throughput (IPS, HTTP)

630 Mbps

SSL Inspection CPS (IPS, avg. HTTPS)

400

SSL Inspection Concurrent Session (IPS, avg. HTTPS)

55,000

Application Control Throughput

1.8 Gbps

CAPWAP Throughput (1444 byte, UDP)

8 Gbps

Virtual Domains (Default / Maximum)

10 / 10

Maximum Number of Switches Supported

16

Maximum Number of FortiAPs (Total / Tunnel Mode)

64 / 32

Maximum Number of FortiTokens

500

High Availability Configurations

Active / Active, Active / Passive, Clustering

Dimensions and Power

Height x Width x Length (inches)

1.5 x 8.5 x 6.3

Height x Width x Length (mm)

38.5 x 216 x 160

Weight

2.23 lbs (1.01 kg)
