FortiSwitch-FS-124E-POE
- Giá bán: Liên hệ
- Dòng sản phẩm: Thiết bị mạng Fortinet
- Tình trạng hàng hóa: Liên hệ
- ● Layer 2 FortiGate switch controller compatible PoE+ switch
● 24 GE RJ45 + 4 SFP ports, 12 port PoE with maximum 185 W limit.
● Form Factor: 1 RU Rack Mount
● Switching Capacity (Duplex): 56 Gbps
Thiết bị FortiSwitch-FS-124E-POE
|
Mã sản phẩm |
FS-124E-PoE |
|
Hardware Specifications |
|
|
Total Network Interfaces |
24x GE RJ45 and 4x GE SFP |
|
Dedicated Management 10/100 Port |
0 |
|
RJ-45 Serial Console Port |
1 |
|
Form Factor |
1 RU Rack Mount |
|
Power over Ethernet (PoE) Ports |
12 (802.3af/at) |
|
PoE Power Budget |
185 W |
|
Mean Time Between Failures |
> 10 years |
|
System Specifications |
|
|
Switching Capacity (Duplex) |
56 Gbps |
|
Packets Per Second (Duplex) |
83 Mpps |
|
MAC Address Storage |
8 K |
|
Network Latency |
4µs |
|
VLANs Supported |
4 K |
|
Link Aggregation Group Size |
8 |
|
Total Link Aggregation Groups |
8 |
|
Packet Buffers |
512 KB |
|
DRAM |
256 MB DDR3 |
|
FLASH |
32 MB |
|
Dimensions |
|
|
Height x Depth x Width (inches) |
1.7 x 12.2 x 17.3 |
|
Height x Depth x Width (mm) |
44 x 309 x 440 |
|
Weight |
11.1 lbs (5.03 kg) |
|
Environment |
|
|
Power Required |
100–240V AC, 50–60 Hz |
|
Power Supply |
AC Built in |
|
Redundant Power |
- |
|
Power Consumption (Average / Maximum) |
202.78 W / 205.45 W |
|
Heat Dissipation |
60.67 BTU/h |
|
Operating Temperature |
32–104°F (0–40°C) |
|
Storage Temperature |
-40–158°F (-40–70°C) |
|
Humidity |
10–90% non-condensing |
|
Certification and Compliance |
FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2 |
