Performance and Capacities

Firewall throughput (HTTP/appmix)

54.2 / 60.0 Gbps

Threat Prevention throughput (HTTP/appmix)

27.1 / 33.8 Gbps

IPsec VPN throughput

28 Gbps

Max sessions

65M

New sessions per second

586,000

Virtual systems (base/max)

25/225

Hardware Specifications

I/O

100/1000/10G Cu (4), 1G/10G SFP/ SFP+ (16), 40G/100G QSFP28 (4)

Management I/O

10/100/1000 (2)
40G/100G QSFP28 HA (1)
10/100/1000 out-of-band management (1)
RJ45 console port (1)

Storage Capacity

240 GB SSD, RAID1, system storage
2 TB HDD, RAID1, log storage

Power Supply (Avg/Max Power Consumption)

571 / 685 W

Max BTU/hr

2,340

Power Supplies (Base/Max)

1:1 fully redundant (2/2)

AC Input Voltage (Input Frequency)

100–240 VAC (50–60 Hz)

AC Power Supply Output

1,200 watts/power supply

Max Current Consumption

AC: 8.5 A @ 100 VAC, 3.6 A @ 240 VAC

Max Inrush Current

AC: 50 A @ 230 VAC, 50 A @ 120 VAC

Mean Time Between Failure (MTBF)

9.12 years

Rack Mount (Dimensions)

3U, 19” standard rack
5.25” H x 20.5” D x 17.25” W

Weight (Standalone Device/As Shipped)

46 lbs / 62 lbs

Safety

cTUVus, CB

EMI

FCC Class A, CE Class A, VCCI Class A
