Standard Support

IEEE 802.11a/n
IEEE 802.11i
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3x flow control

Dimensions (W x D x H)

87 x 38 x 260mm

Weight

405g

Power Requirements

48V DC IN,0.5A, IEEE 802.3 at PoE+ or
12V DC IN, 1.0A from DC Jack

Interface

Wireless IEEE 802.11a/n, 2T2R
PoE: 1 x 10/100BASE-TX, auto-MDI/MDIX, 802.3af/at PoE In
LAN: 1x 10/100BASE-TX, auto-MDI/MDIX

Button

Reset/Pair button, WDS Switch

Antenna

Built-in 15dBi directional antenna with dual polarization
Horizontal: 70 degrees
Vertical: 15 degrees

Data Rate

IEEE 802.11a: up to 54Mbps
IEEE 802.11n (20MHz): up to 150Mbps
IEEE 802.11n (40MHz): up to 300Mbps

Media Access Control

CSMA/CA

Modulation

802.11a/n: OFDM (BPSK/ QPSK/ 16QAM/ 64QAM)

Frequency Band

FCC: 5.180~5.240GHz, 5.745~5.825GHz
ETSI: 5.180~5.700GHz

Max. Transmit Power (dBm)

FCC: up to 27 ± 2dBm
ETSI: < 20dBm (EIRP)

Receiver Sensitivity (dBm)

802.11a
　6Mbps: -92dBm
　54Mbps: -75dBm
802.11n HT20
　MCS0/MCS8: -91dBm
　MCS7/MCS15: -72dBm
802.11n HT40
　MCS0/MCS8: -88dBm
　MCS7/MCS15: -70dBm

Operating Temperature

-20 ~ 70 degrees C

Operating Humidity

5~ 90% (non-condensing)

IP Level

IP55

ESD Protection

± 8kV air-gap discharge
± 4kV contact discharge

Surge Protection

± 4kV
