Mã sản phẩm

NAS QNAP TS-453BT3-8G

CPU

Intel® Celeron® J3455 quad-core 1.5 GHz processor (burst up to 2.3 GHz)

Graphic Processors

Intel® HD Graphics 500

Encryption Engine

Yes (AES-NI)

Hardware-acceleratedTranscoding

Yes

System Memory

8 GB SO-DIMM DDR3L (2 x 4 GB)

Maximum Memory

8 GB (2 x 4 GB)

Memory Slot

2 x SO-DIMM DDR3L

Flash Memory

4GB (Dual boot OS protection)

Drive Bay

4 x 3.5-inch SATA 6Gb/s, 3Gb/s

Drive Compatibility

3.5-inch SATA HDD
2.5-inch SATA HDD
2.5-inch SATA SSD

Hot-swappable

YES

M.2 SSD Slot

2 x M.2 2280 SATA 6Gb/s SSD slots (pre-installed QM2 PCIe card)

SSD Cache Acceleration Support

YES

PCIe Slot

1 x PCIe Gen 2 (x2)
Pre-installed with a QM2 expansion card (QM2-2S10G1TB) thatincludes a 10GbE 10GBASE-T port and two M.2 SATA SSD slots

Gigabit Ethernet Port (RJ45)

2

10 Gigabit/ 5 Gigabit Ethernet Port

1 x 10GBASE-T (10G/5G/2.5G/1G/100M)
Pre-installed QM2 PCIe card

Thunderbolt Port

2 (Thunderbolt™ 3)

USB port

USB 3.0: 5
USB 3.1 Gen 2 (10Gbps): Optional via a PCIe adapter (need to replace the pre-installed QM2 card)

HDMI

2, HDMI 1.4a (up to 3840 x 2160 @ 30Hz)

Audio

Input: 2 x 3.5mm dynamic microphone input jacks
Output: 1 x built-in speaker, 1 x 3.5mm line out jack (for amplifier or headphone amplifier)

Form Factor

Tower

Dimensions (HxWxD)

168 × 170 × 226 mm

Weight

2.51 kg ~ 4.05 kg
