Mã sản phẩm

TS-h1683XU-RP-E2236-128G

CPU

Intel® Xeon® E-2236 6-core 3.4 GHz processor (burst up to 4.8 GHz)

CPU Architecture

64-bit x86

Floating Point Unit

✔

Encryption Engine

✔ (AES-NI)

Maximum Memory

128 GB (4 x 32 GB)

Memory Slot

4 x Long-DIMM DDR4

Flash Memory

5GB (Dual boot OS protection)

Drive Bays

16 x 3.5-inch SATA 6Gb/s, 3Gb/s

Drive Compatibility

3.5-inch bays:
- 3.5-inch SATA hard disk drives
- 2.5-inch SATA hard disk drives
- 2.5-inch SATA solid state drives

Hot-swappable

✔

SSD Cache Acceleration Support

✔

Gigabit Ethernet Port (RJ45)

4

10 Gigabit Ethernet Port

2 x 10GbE SFP+ SmartNIC port, 2 x 10GBase-T port

PCIe Slot

4
- Slot 1: PCIe Gen 2 x4 (PCH)
- Slot 2: PCIe Gen 3 x8 (CPU)
- Slot 3: PCIe Gen 3 x4 (CPU)
- Slot 4: PCIe Gen 3 x4 (CPU)

USB 3.2 Gen 2 (10Gbps) Port

- 2 x Type-C USB 3.2 Gen 2 5V/3A 10Gbps
- 4 x Type-A USB 3.2 Gen 2 5V/1A 10Gbps

Form Factor

3U Rackmount

LED Indicators

HDD 1-16, Status, LAN, storage expansion port status

Buttons

Power, Reset

Dimensions (HxWxD)

130 × 481 × 573.5 mm

Weight (Net)

13.76 kg

Operating temperature

0 - 40 °C  (32°F - 104°F)

Relative Humidity

5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)

Power Supply Unit

500W(x2), 100-240V

Power Consumption

130.43 W

Fan

System fan: 4 x 92mm, 12VDC

Kensington Security Slot

Yes

Max. Number of Concurrent
Connections (CIFS)

700
