SKU

TVS-872X

CPU

● Intel® Core™ i3-8100T 4-core 3.1 GHz Processor
● Architecture: 64-bit x86
● Graphics: Intel® UHD Graphics 630
● Encryption Engine: AES-NI

System Memory

8 GB SO-DIMM DDR4 (1 x 8 GB)

Maximum Memory

64 GB (2 x 32 GB)

Memory Slot

2 x SO-DIMM DDR4

Flash Memory

5GB (Dual boot OS protection)

Drive Bays

8 x 3.5-inch SATA 6Gb/s, 3Gb/s

Drive Compatibility

● 3.5-inch SATA hard disk drives
● 2.5-inch SATA hard disk drives
● 2.5-inch SATA solid state drives

Hot-swappable

✔

M.2 SSD Slot

2 x M.2 2280 PCIe Gen3 x2 slots

SSD Cache Acceleration Support

✔

Gigabit Ethernet Port (RJ45)

2

10 Gigabit Ethernet Port

1 x 10GBASE-T (10G/5G/2.5G/1G/100M)

PCIe Slot

2:
● Slot 1: PCIe Gen 3 x16 (CPU)
● Slot 2: PCIe Gen 3 x4 (PCH)

USB Port

1 x USB 3.2 Gen 1 port
4 x USB 3.2 Gen 2 (10Gbps) Port

IR sensor

✔ (QNAP RM-IR004 & MCE)

HDMI Output

1, HDMI 2.0 (up to 3840 x 2160 @ 60Hz)

Form Factor

Tower

Dimensions (HxWxD)

188.2 × 329.3 × 279.6 mm

Power Consumption (W)

65.03 W

Power Supply Unit

250W, 100-240V

Weight (Net)

7.06 kg

Operating temperature

0 - 40 °C (32°F - 104°F)

Relative Humidity

5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)

Fan

● System: 2 x 120 mm, 12VDC
● CPU: 2 x 60 mm
