THÔNG SỐ KỸ THUẬT
| Cellular | No |
| Ethernet WAN | 7 (GE) |
| Ethernet LAN | 3 (GE) |
| Stateful Firewall Throughput | 2.5 Gbps |
| PepVPN Throughput (No Encryption) | 400 Mbps |
| PepVPN Throughput (256-bit AES) | 400 Mbps |
| SFP LAN/WAN | No |
| Wi-Fi AP | No |
| USB | 1 |
| Recommended Users | 500-2000 |
| Number of PepVPN/SpeedFusion Peers | 300 |
| Maximum Number of AP Supported | 250 |
| SpeedFusion Hot Failover | Yes |
| SpeedFusion WAN Smoothing | Yes |
| SpeedFusion Bandwidth Bonding | Yes |
| Central Management | InContol 2 |
| Drop-In Mode | No |
| High Availability | Yes |
| Content Filtering (Lite/Full) | Full |
| Pepwave AP Series Management | Yes |
| Remote AP & Multiple Config Profiles Management | Yes |
| LAN Bypass | Yes |
| Remote User Access | Yes |
| 802.1q VLANs Supported | 1024 |
| Port-Based VLAN | Yes |
| Load Balancing & Failover | Yes |
| Load Balancing Algorithms | 8 |
| Inbound Load Balancing | Yes |
| InControl Cloud Management | Yes |
| WAN | Support for PPPoE, Static IP, DHCP WAN Link Health Check PING DNS Lookup HTTP Bandwidth Allowance Monitor IPv6 Support USB 4G/3G Modem Support Support for Dynamic DNS services changeip.com dyndns.org no-ip.org tzo.com DNS-O-Matic WAN Port Convertible into LAN Port |
| LAN | DHCP Server for LAN Clients Extended DHCP Option DHCP Reservation DNS Proxy for LAN Clients VLAN on LAN Support |
| Load Balancing | Intelligent Failover Session Persistence Per-Service Load Distribution Multiple Algorithms -Weighted -Enforced -Persistence -Priority -Overflow -Least Used -Lowest Latency |
| Security | DoS Prevention Stateful Firewall Web Blocking |
| VPN | PepVPN/SpeedFusion Bandwidth Bonding -Site-to-Site VPN -Bandwidth Aggregation -Hot Failover -256-bit AES Encryption -Pre-shared Key Authentication -Dynamic Routing -X.509 Certificate Support PPTP/L2TP/OpenVPN Server -Local User, LDAP, RADIUS, Active Directory Authentication IPsec VPN (Network-to-Network) -X.509 Certificate Support GRE Tunnel (Network-to-Network) |
| Advanced QoS | User Groups -Bandwidth Reservation -Individual Bandwidth Limit Application Prioritization -By User Groups -SIP, HTTPS, VPN QoS -Custom Application QoS |
| Networking | NAT and IP Forwarding Static Routes Port Forwarding Many to One, One to One NAT NAT Pool SIP ALG, H.323 ALG UPnP, NAT-PMP WINS Server BGP, OSPFv2 and RIPv2 Support Bonjour Forwarding |
| AP Controller | Support for Pepwave AP Series Auto AP Discovery Auto AP Firmware Management AP Profile Configuration Wi-Fi Usage Statistics |
| Captive Portal | Support for Wired and Wireless LAN Clients Support RADIUS Authentication Support LDAP Authentication Time and Usage Quotas on Open Access Mode Built-in Customizable Splash Page |
| DNS | Built-in Authoritative DNS
-Support for A, CNAME, NS, MX, PTR, SOA, SRV, TXT Records |
| Device Management | Web Administrative Interface Command Line Interface InControl Cloud Management Email Notification Active Client & Session Lists Bandwidth Usage Statistics Syslog Service SNMP v1, v2c and v3 |
| Power | Universal Input 100V – 240V AC |
