CPU |
CPU Model | Intel Celeron J4125 |
|---|---|---|
| CPU Architecture | 64-bit | |
| CPU Frequency | 4-core 2.0 (base) / 2.7 (burst) GHz | |
| Hardware Encryption Engine (AES-NI) | ||
Memory |
System Memory | 8 GB DDR4 non-ECC |
| Memory Module Pre-installed | 8 GB (4 GB + 4 GB) | |
| Total Memory Slots | 1 | |
| Notes |
|
|
Storage |
Drive Bays | 5 |
| Maximum Drive Bays with Expansion Unit | 15 (DX517 x 2) | |
| M.2 Drive Slots | 2 (NVMe) | |
| Compatible Drive Type* (See all supported drives) |
|
|
| Maximum Internal Raw Capacity | 80 TB (16 TB drive x 5) (Capacity may vary by RAID types) | |
| Maximum Raw Capacity with Expansion Units | 240 TB (80 TB + 16 TB drive x 10) (Capacity may vary by RAID types) | |
| Maximum Single Volume Size* | 108 TB | |
| Hot Swappable Drive | ||
| Notes |
|
|
External Ports |
RJ-45 1GbE LAN Port | 4 (with Link Aggregation / Failover support) |
| USB 3.0 Port | 2 | |
| eSATA Port | 2 | |
File System |
Internal Drives |
|
| External Drives |
|
|
| Notes | exFAT Access is purchased separately in Package Center. | |
Appearance |
Size (Height x Width x Depth) | 166 mm x 230 mm x 223 mm |
| Weight | 2.26 kg | |
Others |
System Fan | 92 mm x 92 mm x 2 pcs |
| Fan Speed Mode |
|
|
| Brightness Adjustable Front LED Indicators | ||
| Power Recovery | ||
| Noise Level* | 20.8 dB(A) | |
| Scheduled Power On / Off | ||
| Wake on LAN / WAN | ||
| Power Supply Unit / Adapter | 120 W | |
| AC Input Power Voltage | 100 V to 240 V AC | |
| Power Frequency | 50/60 Hz, Single Phase | |
| Power Consumption* | 36.67 W (Access) 15.51 W (HDD Hibernation) |
|
| British Thermal Unit | 125.21 BTU/hr (Access) 52.96 BTU/hr (HDD Hibernation) |
|
| Notes |
|
|
Temperature |
Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) | |
| Relative Humidity | 5% to 95% RH | |
Certification |
|
|
Warranty |
3-year hardware warranty, extendable to 5-year coverage – EW201 | |
| Notes | The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more) | |
Environment |
RoHS Compliant | |
Packaging Content |
|
|
Optional Accessories |
||
Notes:
- Model specifications are subject to change without prior notice.
- The figures are based on Synology internal testing. No other services or applications are processed during the performance tests.
