Wifi UniFi UAP-AC-HD
|
Model |
UAP-AC-HD |
|
Dimensions |
220 x 220 x 48.1 mm (8.66 x 8.66 x 1.89″) |
|
Weight (Without Mount) |
700 g (1.54 lb) |
|
Weight (With Mounting Kits) |
830 g (1.83 lb) |
|
Networking Interface |
2 Ports 10/100/1000 Ethernet Ports |
|
Buttons |
Reset |
|
Power Method |
802.3at PoE+ |
|
Power Supply |
UniFi Switch (PoE) |
|
Power Save |
Supported |
|
Beamforming |
Supported |
|
Maximum Power Consumption |
17W |
|
Supported Voltage Range |
44 to 57VDC |
|
TX Power |
2.4 GHz: 6-25 dBm |
|
Antennas |
2.4 GHz: (2) Dual-Port, Dual-Polarity Antennas, 3 dBi each |
|
2.4 GHz Radio Rate |
800 Mbps |
|
2.4 GHz MIMO |
4×4 |
|
5 GHz Radio Rate |
1733 Mbps |
|
5 GHz MIMO |
4×4 |
|
Environment |
Indoor or Outdoor (Covered) |
|
Wi-Fi Standards |
802.11 a/b/g/n/ac/ac-wave2 |
|
Wireless Security |
WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES) 802.11w/PMF |
|
BSSID |
Up to 8 per Radio |
|
Mounting |
Wall/Ceiling (Kits Included) |
|
Operating Temperature |
-10 to 70° C (14 to 158° F) |
|
Operating Humidity |
5 to 95% Noncondensing |
|
Certifications |
CE, FCC, IC |
|
Advanced Traffic Management |
|
|
VLAN |
802.1Q |
|
Advanced QoS |
Per-User Rate Limiting |
|
Guest Traffic Isolation |
Supported |
|
WMM |
Voice, Video, Best Effort, and Background |
|
Concurrent Clients |
1000 |
|
Supported Data Rates (Mbps) |
|
|
Standard |
Data Rates |
|
802.11a |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
|
802.11n |
6.5 Mbps to 450 Mbps (MCS0 – MCS23, HT 20/40) |
|
802.11ac |
6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80) |
|
802.11b |
1, 2, 5.5, 11 Mbps |
|
802.11g |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
